        • Remote Monitoring

          Remote monitoring of buildings, machines, vehicles;

          Display of measurement data in the cloud on smartgage.de

          See More

        "smartgage.de"

        ME-Meßsysteme offers with "smartgage.de" functions for

        • the acquisition of measurement data with data logger,
        • the remote control of the data logger,
        • the storage of measurement data (InfluxDB),
        • the display of measurement data (Grafana).

        Hardware for smartgage.de

        An 8-channel measuring amplifier GSV-8DS is used in conjunction with an LTE modem from Advantech to record the measurement data.

        The measuring amplifier and modem are connected via the serial interface of the measuring amplifier. A Python script from ME-Meßsysteme GmbH is installed on the modem, which handles the communication between the measuring amplifier and the modem, and the communication between the modem and the web server.

        "Live" example

        Our Service

        We install the strain gauges or displacement sensors or temperature or humidity sensors on site, set up the hardware, take care of the SIM card for the LTE network, and give you the website "smartgage.de" with your measurement data for graphical viewing and downloading of the measurement data.

        Advantech LTE Modem

        LTE modem with application software "smartgage.de"

        GSV-8 with Modem

        Grafana

        display of measured values ​​with Grafana
