        Art.Nr.: 14836

        DAkkS Calibration Certificate 20kN/10

        • Calibration of the Measurement System
        • "DAkkS-DKD R 3-3 Sequence A"
        • 3 series of measurements in different mounting positions
        • Applying a calibration mark on the device
        • Maximum force alternatively 1N to 20kN
        • Tensile force in 10% steps
        • Measurement of the sensor characteristic value in mV/V and the characteristic value of the measurement chain
        • Adjusting the display
        • Invoicing according to actual expenditure
        • excl. service fee DAKKS calibration external

        Note: When calibrating with tensile force special adapters are required for force transmission.

        Without the adapter, it can lead to longer delivery times. The preparation of the adapter may cause additional costs.



        All details
        Select variant:
        Add to Cart
        Product description
        Artikelbeschreibung
        • Calibration of the Measurement System
        • "DAkkS-DKD R 3-3 Sequence A"
        • 3 series of measurements in different mounting positions
        • Applying a calibration mark on the device
        • Maximum force alternatively 1N to 20kN
        • Tensile force in 10% steps
        • Measurement of the sensor characteristic value in mV/V and the characteristic value of the measurement chain
        • Adjusting the display
        • Invoicing according to actual expenditure
        • excl. service fee DAKKS calibration external

        Note: When calibrating with tensile force special adapters are required for force transmission.

        Without the adapter, it can lead to longer delivery times. The preparation of the adapter may cause additional costs.



        Product description

        DAkkS calibration certificates are issued by a DAkkS accredited calibration laboratory.

        Calibration is carried out by "MPA Kalibrierdient GmbH" in Berlin,
        an accredited calibration laboratory according to DIN EN ISO / IEC 17025
        Akk.Nr. D-K-17552-01-00

        with recognition by the Federal Railway Authority
        VMPA-testing
        http://www.mpa-kalibrierdienst.de/?page_id=13

        The force gauges are calibrated to the force reference standard means the Federal Institute for Materials Research and Testing (BAM), which are connected via the Physikalisch-Technische Bundesanstalt in Braunschweig to the national force standard.
