        Art.Nr.: 6389

        Factory calibration certificate Nm/50/5/System

        • Calibration of the measuring chain (torque sensor + measuring amplifier);
        • 3 measuring series with 5 measuring points each;
        • Measurement of the span, the relative characteristic deviation and the relative linearity deviation;
        • Measurement of the insulation resistance, the sensor characteristic value, the zero deviation of the sensor;
        • Measurement of the zero point return error;
        • Proof of traceability to DAkkS;
        • Place a calibration mark on the device;
        • Maximum torque alternatively 0.025Nm ... 50Nm;
        • Right torque: 0% -25% -50% -75% -100% -0%;
        • Left torque: 0% -25% -50% -75% -100% -0%;
        • Measurement of the sensor characteristic value in mV/V and the characteristic value of the measuring chain;
        All details
        Add to Cart
        Product description
        Artikelbeschreibung
        • Calibration of the measuring chain (torque sensor + measuring amplifier);
        • 3 measuring series with 5 measuring points each;
        • Measurement of the span, the relative characteristic deviation and the relative linearity deviation;
        • Measurement of the insulation resistance, the sensor characteristic value, the zero deviation of the sensor;
        • Measurement of the zero point return error;
        • Proof of traceability to DAkkS;
        • Place a calibration mark on the device;
        • Maximum torque alternatively 0.025Nm ... 50Nm;
        • Right torque: 0% -25% -50% -75% -100% -0%;
        • Left torque: 0% -25% -50% -75% -100% -0%;
        • Measurement of the sensor characteristic value in mV/V and the characteristic value of the measuring chain;
