Art.Nr.: 6594

Calibration Certificate kn/20/5/K3D

  • Calibration of the measuring chain (3-axis force sensor + measuring amplifier);
  • 3 series of measurements with 5 measuring points;
  • Measurement of the relative reproducibilty, the relative deviation of characteristic curve and the relative linearity error;
  • Measurement of insulation resistance of the characteristic value, the zero signal of the sensor;
  • Measurement of the zero signal hysteresis;
  • Measurement of cross talk;
  • Traceability to DAkkS force measurement standards;
  • Applying a calibration mark on the device;
  • Maximum force alternatively 1N to 20kN;
  • Compressive force 0%, 25%, 50%, 75%, 100%, 0%;
  • Measurement of the sensor characteristic in mV/ V and the characteristic of the measurement system;
All details
Select variant:
Artikelbeschreibung
  • Calibration of the measuring chain (3-axis force sensor + measuring amplifier);
  • 3 series of measurements with 5 measuring points;
  • Measurement of the relative reproducibilty, the relative deviation of characteristic curve and the relative linearity error;
  • Measurement of insulation resistance of the characteristic value, the zero signal of the sensor;
  • Measurement of the zero signal hysteresis;
  • Measurement of cross talk;
  • Traceability to DAkkS force measurement standards;
  • Applying a calibration mark on the device;
  • Maximum force alternatively 1N to 20kN;
  • Compressive force 0%, 25%, 50%, 75%, 100%, 0%;
  • Measurement of the sensor characteristic in mV/ V and the characteristic of the measurement system;
Product description

The factory calibration takes into account the requirements of DIN EN ISO / IEC 17025 and ISO 9000. The calibration certificate serves as proof of test equipment according to DIN ISO 9001: 2008.

Documented and evaluated are

  •          the general state of the sensor
  •          the span (reproducibility)
  •          the characteristics - and linearity error

at different load levels.

Note: For calibration with traction special adapters are needed for introducing force.

Without an adapter, it can lead to longer delivery times. The production of the adapter may cause additional costs.
