        Art.Nr.: 13038

        Calibration Certificate mm/100/x

        • Calibration of the measuring chain (displacement sensor+measuring amplifier);
        • 3 measurement series with 5 measurement points each;
        • Measurement of span, relative characteristic deviation and relative linearity deviation;
        • Measurement of the insulation resistance, the sensor characteristic value, the zero deviation of the senso;
        • Measurement of the zero return error;
        • Proof of traceability to DAkkS cApplication of a calibration mark to the instrument;
        • Maximum travel alternatively 1mm to 100mm;
        • 0%, 25%, 50%, 75%, 100%, 0%;
        All details
        Select variant:
        Add to Cart
        Product description
        Artikelbeschreibung
        • Calibration of the measuring chain (displacement sensor+measuring amplifier);
        • 3 measurement series with 5 measurement points each;
        • Measurement of span, relative characteristic deviation and relative linearity deviation;
        • Measurement of the insulation resistance, the sensor characteristic value, the zero deviation of the senso;
        • Measurement of the zero return error;
        • Proof of traceability to DAkkS cApplication of a calibration mark to the instrument;
        • Maximum travel alternatively 1mm to 100mm;
        • 0%, 25%, 50%, 75%, 100%, 0%;
