        Art.Nr.: 7758

        Configuration GSV-6

        Configuration of GSV-6K and GSV-6L::
        Measuring range

        • according to characteristic value of the sensor (standard) or
        • TEDS or
        • fixed at 0.1; 0.2; 0.5; 1.0, 2.0, 4.0mV / V, 8.0mV / V;

        Output signal

        • Voltage output -10V ... + 10V (standard) or
        • Current output 4 ... 20mA or
        • Voltage output -5V ... + 5V or ...;

        Offset

        • 0% (standard) or
        • 50% or ...

        Frequency

        • 10Hz (standard) or
        • 50Hz, 100Hz, 500Hz, 1kHz, 5kHz, 10kHz, 25kHz
        All details
        Add to Cart
        Product description
        Instructions
        Artikelbeschreibung

        Configuration of GSV-6K and GSV-6L::
        Measuring range

        • according to characteristic value of the sensor (standard) or
        • TEDS or
        • fixed at 0.1; 0.2; 0.5; 1.0, 2.0, 4.0mV / V, 8.0mV / V;

        Output signal

        • Voltage output -10V ... + 10V (standard) or
        • Current output 4 ... 20mA or
        • Voltage output -5V ... + 5V or ...;

        Offset

        • 0% (standard) or
        • 50% or ...

        Frequency

        • 10Hz (standard) or
        • 50Hz, 100Hz, 500Hz, 1kHz, 5kHz, 10kHz, 25kHz
